型号Model | 单位 Uite | CGL400/300 | CGL600/500 | CGL980/1240 | CGL1000/1900 | CGL1060/2900 | CGL1400/2300 |
给料粒度 | mm | 50 | 205 | 300 | 300 | 350 | 300 |
槽底往复次数 | r/min | 18.5 | 18.9 | 24 | 27 | 30 | 30.85 |
曲柄行程 | mm | 0-50 | 0-50 | 0-50 | 0-125 | 0-125 | 90-150 |
处理量 | t/h | 0-5 | 10-50 | 36-90 | 200-300 | 400-900 | 430-900 |
功率 | kw | 3 | 4 | 7.5 | 11 | 25-40 | 18.5 |
外形 | mm | 2820/800/600 | 2700/900/850 | 3560/1000/1000 | 3900/1590/1350 | 4580/2950/1750 | 4460*2090*3804 |
重量Weight | kg | 790 | 1050 | 1700 | 2690 | 3200 | 6895 |
